Dot laser, red, 650 nm, 1 mW, 3 V DC, Ø4x20 mm, Laser Class 2, Focus fixed (4.0m), Cable length 80…

Fokussierbarer Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus einstellbar, 3V DC, 12x30.5mm The type is a dot laser that projects a red laser dot. The laser module includes a adjustable optics. Accordingly, it can be set optimally to fit your application. The laser module has a controller electronic and just needs to be attached to a power supply (). Caused by laser classification , no TÜV-registration is necessary. The laser can be applied e.g. in discotheque events and it can be mounted in tools without any problems. (The laser protective measures are still to be considered.)The power consumption of is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. Typical operation areas are low cost applications. The working life of the laser module exceeds .You may use our battery pack with 2 x 1.5 volt batteries as power supply. Operating Voltage 3V DC Laser Class 2 Low cost Adjustable focus Compact size Abstrahlcharakteristik: elliptischer Punkt, Punktgröße veränderbar Optische Leistung: 1mW (Laserklasse 2); Fokus einstellbar Kompakte Bauform: 12x30.5mm; Achsabweichung: bis zu 3,0° Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, in Industrie, Handwerk, Hobby und dem Showbereich. Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden. Accessesories Magnetic Mount for Lasermodul 12mm12mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 12mm Magnetic Mount for 12mm Laser ModuleØ12mm (36x62) Magnetic holder for 12mm laser module, diameter 36mm, height 62mm, plastic Magnetic Mount for Lasermodul 12mmØ12mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 12mm Mount for Lasermodul 12mmØ12mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 12mm Mount for Lasermodul 12mmØ12mm(20x57) MOUNT für Lasermodule mit Durchmesser 12mm Bracket for Lasermodule 12mmØ12mm(25x70) Halterung-Ballhead für Lasermodule mit Durchmesser 12mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Bracket for Lasermodule 12mm Main Data EAN: 4260129041230 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Size of Laserdot: adjustable Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: adjustable Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 5 - 15, typ 10 mA Cable color positive: red Cable color GND: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø12x30.5 mm Material: Brass Cable length: 90 mm Wire type: 26AWG, 0,14mm² Output Aperture: 3 mm Weight: 15 g Buy LFD650-1-3(12x30.5) on Amazon

Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus kollimiert, 3V DC, 8x23mm The type LFD650-1-3(8x23) is a dot laser that projects a red laser dot. Caused by laser classification 2, no TÜV-registration is necessary. The laser can be applied e.g. in discotheque events and it can be mounted in tools without any problems. (The laser protective measures are still to be considered.)The laser module has a controller electronic and just needs to be attached to a power supply. Typical operation areas are low cost applications. The power consumption of 15mA is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. The working life of the laser module exceeds 3000h.You may use our battery pack with 2 x 1.5 volt batteries as power supply. Operating Voltage 3 V DC Laser Class 2 Fixed focus Low cost Compact size Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <4..6mm@5m Optische Leistung: 1mW (Laserklasse 2); Fokus kollimiert Sehr Kompakte Bauform: 8x23mm; Achsabweichung: bis zu 3,0° Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, Hobby, Handwerk, der Industrie und dem Showbereich. Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden. Accessesories Bracket for Lasermodule 8mmØ8mm(58x145) LF-Halterung für Lasermodule mit Durchmesser 8mm Magnetic Mount for Lasermodul 8mmØ8mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 8mm Magnetic Mount for Lasermodul 12mmØ8mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 8mm Mount for Lasermodul 08mmØ8mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 8mm Bracket for Lasermodule 8mmØ8mm(25x66) Halterung-Ballhead für Lasermodule mit Durchmesser 8mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4260129041117 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: G - 0.8 mrad Beam Diameter: 3.5 mm Size of Laserdot: <4..6mm@5m Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: collimated Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.6 - 3.3, typ 3 V DC Operating Current: 10 - 25, typ 15 mA Cable color positive: red Cable color GND: white Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø8x23 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 3.5 mm Weight: 3.5 g Buy LFD650-1-3(8x23) on Amazon

Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus 5m, 3V DC, 12x32mm, Restposten Remaining stock: The type is a dot laser that projects a red laser dot.Caused by laser classification , no TÜV-registration is necessary. The laser can be applied tools without any problems. (The laser protective measures are still to be considered.)The laser module has a controller electronic and just needs to be attached to a power supply (). Typical operation areas are low cost applications. The power consumption of is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. The working life of the laser module exceeds .You may use our battery pack with 2 x 1.5 volt batteries as power supply. Operating Voltage 3 V DC Low cost Laser Class 2 Fixed focus Remaining stock Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <4..6mm@5m Optische Leistung: 1mW (Laserklasse 2); Fokus 5m Kompakte Bauform:12x32mm; Achsabweichung: bis zu 3,0°, Taster zur Aktivierung auf Platine, Gehäuse (+), Feder (GND) Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, in Industrie, Handwerk, Hobby, Robotertechnik und dem Showbereich. Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden. Accessesories Magnetic Mount for Lasermodul 12mm12mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 12mm Magnetic Mount for 12mm Laser ModuleØ12mm (36x62) Magnetic holder for 12mm laser module, diameter 36mm, height 62mm, plastic Magnetic Mount for Lasermodul 12mmØ12mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 12mm Mount for Lasermodul 12mmØ12mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 12mm Mount for Lasermodul 12mmØ12mm(20x57) MOUNT für Lasermodule mit Durchmesser 12mm Bracket for Lasermodule 12mmØ12mm(25x70) Halterung-Ballhead für Lasermodule mit Durchmesser 12mm Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Bracket for Lasermodule 12mm Main Data EAN: 4055132001322 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: G - 0.8 mrad Beam Diameter: 2.5 mm Size of Laserdot: <4..6mm@5m Optics: glass lens AR coated Laser technology: diode Focus: fixed (5.0m) Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 10 - 25, typ 15 mA Mechanical Parameters Size: Ø12x32 mm Material: Brass Output Aperture: 2.5 mm Weight: 6 g Buy RP-LFD650-1-3(12x32)-V1 on Amazon

Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus 5m, 3V DC, 12x32mm The type is a dot laser that projects a red laser dot.Caused by laser classification , no TÜV-registration is necessary. The laser can be applied e.g. in discotheque events and it can be mounted in tools without any problems. (The laser protective measures are still to be considered.)The laser module has a controller electronic and just needs to be attached to a power supply (). Typical operation areas are low cost applications. The power consumption of is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. The working life of the laser module exceeds .You may use our battery pack with 2 x 1.5 volt batteries as power supply. Operating Voltage 3 V DC Low cost Laser Class 2 Fixed focus Small laser head Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <4..6mm@5m Optische Leistung: 1mW (Laserklasse 2); Fokus 5m Kompakte Bauform:12x32mm; Achsabweichung: bis zu 3,0°, Taster zur Aktivierung auf Platine, Gehäuse (+), Feder (GND) Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, in Industrie, Handwerk, Hobby, Robotertechnik und dem Showbereich. Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden. Accessesories Magnetic Mount for Lasermodul 12mm12mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 12mm Magnetic Mount for 12mm Laser ModuleØ12mm (36x62) Magnetic holder for 12mm laser module, diameter 36mm, height 62mm, plastic Magnetic Mount for Lasermodul 12mmØ12mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 12mm Mount for Lasermodul 12mmØ12mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 12mm Mount for Lasermodul 12mmØ12mm(20x57) MOUNT für Lasermodule mit Durchmesser 12mm Bracket for Lasermodule 12mmØ12mm(25x70) Halterung-Ballhead für Lasermodule mit Durchmesser 12mm Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Bracket for Lasermodule 12mm Main Data EAN: 4260129041131 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 5,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: G - 0.8 mrad Beam Diameter: 2.5 mm Size of Laserdot: <4..6mm@5m Optics: glass lens AR coated Laser technology: diode Focus: fixed (5.0m) Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 4 - 25, typ 15 mA Mechanical Parameters Size: Ø12x32 mm Material: Brass Output Aperture: 2.5 mm Weight: 6 g Buy LFD650-1-3(12x32) on Amazon
