Doe laser, red, 635 nm, 3.5 mW, 6 V DC, Ø10x22 mm, Laser Class 2M, Focus fixed, Cable length 100 mm
€46.84*
Available in 21 days, delivery time 1-2 days
Product information "Doe laser, red, 635 nm, 3.5 mW, 6 V DC, Ø10x22 mm, Laser Class 2M, Focus fixed, Cable length 100 mm"
DOE lasermodule, red, 635nm, 5mW, 3-12V DC, 10x22mm, class 2M, incl. custom-made DOE
- DOE optimized
- Laserclass depends on DOE
- Compact size
- Wide operating voltage
- Low cost
Accessesories
Magnetic Mount for Lasermodul 10mm
10mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 10mm
Magnetic Mount for Lasermodul 12mm
Ø10mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 10mm
Mount for Lasermodul 10mm
Ø10mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 10mm
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development
Main Data
- Warranty: 1 years
- Customs tariff number: 90132000000
Technical Parameters
- Lifetime: > 3,000 h
- Operating Temperature: -20°C - 50 °C
- Storage Temperature: -40°C - 80 °C
Optical Parameters
- Beam Shape: DOE
- Optical Power: 3.5 mW
- Laser Class: 2M
- Divergence: G - 0.8 mrad
- Operating Distance: 10 m
- Optics: acryl lense
- Laser technology: diode
- Focus: fixed
Electrical Parameters
- Potential of Housing: VDD(+)
- Operating Voltage: 3 - 6, typ 6 V DC
- Operating Current: 20 - 60, typ 45 mA
- Cable color positive: red
- Cable color GND: black
Mechanical Parameters
- Size: Ø10x22 mm
- Material: Brass
- Cable length: 100 mm
- Wire type: 26AWG, 0,14mm²
- Output Aperture: 3 mm
- Housing Color: black
- Weight: 8.5 g
Product Safety Information
Manufacturer
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
Responsible Economic Operator
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
| Optical diode power: | 3,5 mW |
|---|
