Laser Lasermodul Punktlaser rot 650nm 1mW 3-6VDC

Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus kollimiert, 3-6V DC, 9x20mm, Kabel 0,2m

The type LFD650-1-6(9x20)-C200 is a dot laser that projects a red laser dot. This laser module can be operated without series resistor or control electronics. It can be simply attached to existing power supplies e.g. power supply units of small electrical devices. The laser module has a controller electronic and just needs to be attached to a power supply. Caused by laser classification 2, no TÜV-registration is necessary. The laser can be applied e.g. in discotheque events and it can be mounted in tools without any problems. (The laser protective measures are still to be considered.)The power consumption of 25mA is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. Typical operation areas are low cost applications. The working life of the laser module exceeds 3000h.You may use our battery pack with 2 x 1.5 volt batteries as power supply.

• Optimized for 3-6V DC
• Low cost
• Laser Class 2
• Compact size
• Fixed focus

• Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <4..5mm@5m
• Optische Leistung: 1mW (Laserklasse 2); Fokus kollimiert
• Kompakte Bauform:9x20mm; Achsabweichung: bis zu 3,0°, Kabellänge 0,2m
• Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik und dem Showbereich.
• Spannungsversorgung 3V bis 6V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden.

Accessesories

Magnetic Mount for Lasermodul 12mm
Ø9mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 9mm Magnetic Mount for Lasermodul 9mm
09mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 9mm Bracket for Lasermodule 9mm
Ø9mm(25x67) Halterung-Ballhead für Lasermodule mit Durchmesser 9mm Mount for Lasermodul 9mm
Ø9mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 9mm Power supply 3V DC (1200mA)
Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development

Main Data

• EAN: 4055132015695
• Warranty: 1 years
• Customs tariff number: 90132000000

Technical Parameters

• Lifetime: > 3,000 h
• Operating Temperature: -20°C - 40 °C
• Storage Temperature: -40°C - 80 °C

Optical Parameters

• Beam Shape: Dot
• Optical Power: 1 mW
• Laser Class: 2
• Divergence: H - 1.0 mrad
• Beam Diameter: 3 mm
• Size of Laserdot: <4..5mm@5m
• Operating Distance: 10 m
• Optics: acryl lense
• Laser technology: diode
• Focus: collimated

Electrical Parameters

• Operating Voltage: 3 - 6, typ 3 V DC
• Operating Current: 3 - 30, typ 6 mA
• Cable color positive: red
• Cable color GND: black
• Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max.

Mechanical Parameters

• Size: Ø9x20 mm
• Material: Brass
• Cable length: 200 mm
• Wire type: 26AWG, 0,14mm²
• Output Aperture: 3 mm
• Weight: 6 g
