Kreuzlaser Kreuz Laser rot 650nm 1mW 45° 3-12VDC Fokus 100mm

€21.90*

Prices incl. VAT. No shipping costs for orders over 100 Euro in the EU

Available, delivery time: 1-2 days

Product number: 70148251

Product information "Kreuzlaser Kreuz Laser rot 650nm 1mW 45° 3-12VDC Fokus 100mm"

cross lasermodule, red, 650nm, 1mW, 45°, class 1, focus 0.1m, 3-12V DC, 9x20mm, potential of housing VDD(+)

The type LFC650-1-12(9x20)45-70148251 is a laser that projects a red laser cross. This laser module emits light of the wavelength 650nm. The diode laser module measures 9x20mm. The fan angle of 45° generates a laser cross of 0.08m length at a working distance of 0.1m. The operating voltage is 3 to 12 volts. This positioning laser is an universal tool for industry, hobby and trade. It reduces the effort that has to be put into positioning and alignment tasks. This module is laser class 1.

Abstrahlcharakteristik: Kreuz, Liniendicke <1mm@0,1m;
Optische Leistung: 1mW (Laserklasse 1); Fokus 0,1m
Kompakte Bauform: 9x20mm; Öffnungswinkel: 45°; Achsabweichung: bis zu 3,0°; Gehäusepotential VDD(+)
Der Öffnungswinkel (45°) erzeugt, bei einem Arbeitsabstand von 0,1m, eine Laserlinienlänge von 0,08m.
Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik und dem Showbereich. Stromversorgung 3V bis 12V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V verwenden.

Accessesories

Magnetic Mount for Lasermodul 12mm
Ø9mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 9mm Magnetic Mount for Lasermodul 9mm
09mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 9mm Bracket for Lasermodule 9mm
Ø9mm(25x67) Halterung-Ballhead für Lasermodule mit Durchmesser 9mm Mount for Lasermodul 9mm
Ø9mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 9mm Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development

Main Data

Warranty: 1 years
Customs tariff number: 90132000000

Technical Parameters

Lifetime: > 3,000 h
Operating Temperature: -20°C - 40 °C
Storage Temperature: -40°C - 80 °C

Optical Parameters

Beam Shape: Cross
Optical Power: 0.75 mW
Laser Class: 1
Divergence: H - 1.0 mrad
Fan Angle: 45 °
Line Thickness: <1mm@0.1m
Operating Distance: 0.1 m
Optics: acryl lense
Laser technology: diode
Protection Lens: yes
Focus: fixed (100mm)

Electrical Parameters

Potential of Housing: VDD(+)
Operating Voltage: 3 - 12, typ 3 V DC
Operating Current: 5 - 20, typ 15 mA
Cable color positive: red
Cable color GND: black

Mechanical Parameters

Size: Ø9x20 mm
Material: Brass
Cable length: 100 mm
Wire type: 26AWG, 0,14mm²
Output Aperture: 6 mm
Weight: 5.5 g
Protection Class: IP 54
Stripping of wire: 5 mm

Product Safety Information

Manufacturer

Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de

Responsible Economic Operator

Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de

Optical diode power:	0,75 mW
